見出番号 |
部品番号 |
部品名 |
数量 |
1 |
420912422 |
Timing/Drive-Cover-Ass'y-1603-NA.-Includes-1-to-9×1個
|
|
2 |
420232482 |
BUSHING-NEEDLE
Needle-Bushing×1個
|
|
3 |
420641317 |
PLUG SCREW
Plug-Screw-M20-X-1.5×4個
|
|
6 |
420632010 |
PIN-CENTER
Center-Pin-8-X-12×2個
|
|
7 |
420232103 |
DOUBLE SEALED BEARING
Double-Sealed-Bearing×1個
|
|
9 |
420460986 |
OIL PLUG
Oil-Plug×1個
|
|
10 |
420889729 |
Stator-Plate-650W×1個
|
|
11 |
420641258 |
SCREW TORX FLANGE M6 X 35
Flanged-Torx-Screw-M6-X-35×3個
|
|
12 |
420926300 |
RETAINING PLATE
Retaining-Plate×1個
|
|
13 |
420641048 |
TORX FLANGE SCREW
Flanged-Torx-Screw-M6-X-16×2個
|
|
14 |
420685640 |
Magneto-Flywheel,-650W×1個
|
|
15 |
420966851 |
TRIGGER WHEEL
Trigger-Wheel×1個
|
|
16 |
420835163 |
STARTER GEAR 86T
Starter-Gear,-86-Teeth×1個
|
|
19 |
420888041 |
Starter-Drive×1個
|
|
20 |
420238300 |
SPRING-DISK
Spring-Washer×2個
|
|
21 |
420827280 |
THRUST WASHER
Thrust-Washer×1個
|
|
22 |
420888995 |
ELECTRIC STARTER ASSY
Electric-Starter-Ass'y×1個
|
|
23 |
420631310 |
O-RING
O-Ring.-Included-in-Gasket-kit×2個
|
|
24 |
420881340 |
CARBON BRUSH SET
Carbon-Brush-Set×1個
|
|
25 |
420834522 |
STARTER GEAR 9 T
Starter-Gear,-9-Teeth×1個
|
|
26 |
420845601 |
RETAINING RING
Retaining-Ring×1個
|
|
27 |
420641238 |
SCREW-TORX FLANGE
Flanged-Torx-Screw-M6-X-25×2個
|
|
28 |
420966570 |
CRANK POSITION SENSOR
Crankshaft-Position-Sensor-Ass'y×1個
|
|
29 |
420431580 |
O RING
O-Ring.-Included-in-Gasket-kit×1個
|
|
30 |
420641048 |
TORX FLANGE SCREW
Flanged-Torx-Screw-M6-X-16×1個
|
|
31 |
420931130 |
GASKET
Gasket.-Included-in-Gasket-kit×1個
|
|
32 |
420853414 |
CLAMP
Clamp×1個
|
|
33 |
420641258 |
SCREW TORX FLANGE M6 X 35
Flanged-Torx-Screw-M6-X-35×10個
|
|
34 |
420641228 |
TORX FLANGE SCREW
Flanged-Torx-Screw-M6-X-85×11個
|
|
35 |
420220934 |
Input-Shaft×1個
|
|
36 |
420244034 |
Spacer×1個
|
|
37 |
420250056 |
O-Ring×2個
|
|
